Umini Ⅲ Pro
An upgraded version of the Umini III product line, this COB display is perfect for the most demanding of applications with higher brightness, contrast ratios and data speeds. Selected for broadcast, design environments, movie playback, esports and more, this screen is the pinnacle of COB performance. Available in 0.9 and 1.2 pixel pitches. Including Unilumin’s patented EBL+ technology, a series of surface coatings which offer further optical benefits such as low reflection, anti-moire, anti-glare and anti-blue light.
Pixel Pitch:
0.9 mm – 1,.2 mm
High contrast
Thanks to our EBL+ technology and multi-layer optical processing technology, we achieve a contrast of up to 30,000:1, depending on brightness.
Eye protection
Our Umicro & Umini III series has been awarded by TÜV and protects your eyes (blue light).
Energy saving
Using the latest Common Cathode & RGB Flip Chip technology, our modules consume up to 60% less energy.
Ultimate colour quality
The high contrast and low reflectivity ensure a clear image.
Ultra slim and light
The Umicro & Umini III series is only 40 mm thick and weighs only 6 kg/cabinet.
Low heat emission
Even when in continuous operation, our LED walls remain “cool” thanks to the latest technology and unique heat-dissipation technology.
Low-emission product
Our products have a positive CO2 footprint certification according to “DIN EN ISO 14064 – Product Carbon Footprint” from TÜV SÜD.
Specifications
| Umini Ⅲ 0.9 Pro | Umini Ⅲ 1.2 Pro | |
|---|---|---|
| Pixel Pitch | 0.9375 mm | 1.25mm |
| Dimensions | 600 x 337.5 x 40 mm | 600 x 337.5 x 40 mm |
| Brightness | 600 nits / 1,200 nits | 600 nits / 1,200 nits |
| Aspect ratio | 16:9 | 16:9 |
| Contrast | 15,000:1 / 20,000:1 | 15,000:1 / 20,000:1 |
| LED type | Mini LED (Flip Chip COB) | Mini LED (Flip Chip COB) |
| Refresh rate | 3,840 Hz | 3,840 Hz |
| Service access | Front | Front |
| Video frame rate | 50/60 Hz | 50/60 Hz |
| Protection class | IP50 | IP50 |
| Resolution | 640x360 px | 480x270 px |
| Viewing angle horizontal | 180° | 180° |
| Viewing angle virticle | 180° | 180° |
| Weight | 6 kg | 6 kg |
